Complete with 4 bracket kits for the following applications:
“A” BRACKETS
Same – Lamborghini – Deutz – Hurlimann 2.8029.900.0/10
Antonio Carraro 5175526
Goldoni 02050153
Fiat – CNH 47447023
Ferrari F0825404050
Pasquali P170364010001
Case IH 1984880C1
“B” BRACKETS
Fiat – CNH 5186962 – 47447024
“C” BRACKETS
Antonio Carraro 46706011 – 46706002
“D” BRACKETS
Fiat – CNH 5089987 (right side) – 5089988 (left side) ATTENTION: on some versions it may be necessary to cut one of the four fixing tabs to adapt the headlight to the right or left side

Rated voltage: 10-30V DC
IP69K protection rating
Functions: High beam, low beam, position light (white and orange)
Rated power:
– High beam: 40 W
– Low beam: 20 W
– Position: 6 W
– Position connections: white wire for white light, orange wire for orange light – if the position light is not provided on the headlight, the wire does not need to be connected.
Current consumption:
– High beam 12V: 3.33A, 24V: 1.66A;
– Low beam: 12V: 1.66A, 24V: 0.83A;
– Parking light 12V: 0.50A, 24V:0.25A
Certifications: CE, RoHS, REACH, IP69K, CISPR 25 Class 3
Electrical connection: 3-way H4 connector with 190mm cable length.
Headlight body: Aluminum
Side: can be mounted on either the right or left side
Lens material: PC POLYCARBONATE
Approvals: ECE-R10, ECE-R149, ECE-R148 (Orange position light approved for circulation in non-EU countries)
Operating temperature: -40°C / +80°C
