– Connection: pushing the male part
– Disconnection: by pulling the male part
– Occlusion: with protruding valve.
– Connectability: in the absence of pressure.
– Disconnection under pressure: only as an emergency operation.
– Interchangeability: ISO 7241-1 part A standard

Male thread DIN 2353
External diameter – D 38 mm
Length – B 62.3 mm
Length – L 97.3 mm
Chiave – CH 27 mm
Thread – A M18x1.5
CPV Series
