FEMALE PUSH-PULL QUICK COUPLING 1/2″ GAS – CERMAG – 82773
€69,97 (€57,35 + VAT)
Availability: 4 available - Ships in 2/3 business days
– Connection: pushing the male part (push).
– Disconnection: pulling the male part (pull).
– Occlusion: with protruding valve.
– Connectability: male and female parts under pressure with a single operation.
– Disengagement under pressure: only as an emergency operation.
– Interchangeability: ISO 7241-1 part A standard.
ATTENTION: the 4SRPV series replaces the 4SFPV and 4SEPV series
Female Thread – 1/2″ Gas = 21 mm.
External diameter 38 mm
Length 107.3 mm
Chiave – CH 27 mm
Series 4SRPV – 4SRHF
- Additional information
Additional information
| Net weight | 0,55 kg |
|---|---|
| Brand | CERMAG |
