Joints with 20 mm hole diameter. Minimum center distance 357 mm. All closed.
M14x1.5 threaded connections, 220 mm centre distance, aligned
12 mm threaded connection projection.
Cylinder external diameter 58 mm.
cylinder rod diameter 22 mm.
Adaptable to Fiat – Agrifull – Same – Lamborghini tractors
ATTENTION:
On some older models it may be necessary to modify the pipes and fittings
On compact tractors the hitches may interfere with the frame
