FRONT WHEEL HUB – ANTONIO CARRARO – 32013029
Availability: Not available
external diameter of flange 110 mm.
4 thread holes M14x1.5 centre distance 60×85 mm.
wheel centering diameter 50 mm.
bearing seat diameter 45 mm.
total height 67 mm.
internal keying diameter 27×30 mm. with 16 grooves
Applications to be checked with chassis number:
TIGRE 3100 (MY 07) (2400 rpm) (15-15275->)
TIGRE 3100 (3000 rpm) (15-11640 -> 15458)
TIGRE 3200 (MY 07) (15-15194->)
Bitrac (-> 15-03120)
Tigre 2000 (-> 15-09599)
Tigre 2500 (-> 15-12042)
Tigre 2600 (-> 15-11748)
Tigre 2700 (-> 15-09759)
Tigre RS (-> 15-03895)
Tigretrans (-> 55-09819)
Tigretrans 2600 (-> 55-11208)
Tigrotto RS (-> 15-02276)
Tigrottotrans (-> 55-09678)
Bitrac HS (16-00161 -> 16-01383)
Tigretrac 3000 ASA (16-00161 -> 16-01166)
- Additional information
Additional information
| Net weight | 1,3 kg |
|---|---|
| Brand | ANTONIO CARRARO |
This product is currently out of stock.
Don't worry: enter your email address and we'll notify you when it's back in stock.
Codifiche precedenti e successive
No previous encodings are available.
No subsequent encodings are available.
