Simplify the lubrication procedure and reduce time
necessary to execute it
Designed to minimize the activities of
manual lubrication, the cordless grease gun
TLGB 1262-E simplifies and speeds up the procedure
lubrication, simplifying the correct maintenance of the
equipment. The three point base keeps the gun in
vertical and stable position without constituting an encumbrance,
allowing access to restricted areas and reducing
operator fatigue during lubrication.
Equipped with new generation drive and handle e
optimized features, it is easy to handle and
practical for occasional or daily use. It is also suitable
for applications in the agricultural, automotive and ed
construction, as well as for maintenance and industrial applications
generic.
– Simplicity that lasts
– Frees clogged fittings that would otherwise require
replacement in the case of manual grease guns
– Built-in LED illuminates the work area
– Air trapped in the grease gun can
easily eliminate through the vent valve for
restore priming
– Double lip follower design allows for
dispense loose or cartridge fat, eliminating the
fat bypass
– The high pressure hose is equipped with protections
anti-crease elastic bands on each end
– Easy and clean filling from kegs using the
suitable pumps
– LED light for battery charge
Grease delivery 95 ml/min (3.2 oz/min) at one push
of 70 bars
Maximum working pressure 241 bar (3,500) psi
Maximum peak pressure 551 bar (8,000 psi)
Delivery autonomy per battery charge 2.25 cartridges
(contropressione 200 bar)
6.5 cartridges (free flow)
Pipe length 760 mm (30 inches)
Battery type Li-ion
Energy supplied by the 12 V battery
Battery capacity 1,500mAh
Charger voltage, V/Hz 200-240V/50-60Hz
Dimensions of the carrying case 590×108×373 mm
Weight (including battery) 2.5 kg (5.5 lb)
Total weight (including case) 5.98 kg (13.18 lb)
