4-hole coupling flange diameter 8.5 int. 72×101 mm.
flange centering diameter 80 mm.
keyed shaft diameter 13.5×16.5 mm. with 9 splines
pump length 180 mm. from the support surface
Total length 200 mm. including shaft
main pump connections thread M6x1 center distance 35-40 mm.
secondary pump connections M14x1.5 and M18x1.5 mm threads.
counterclockwise rotation shaft side
ATTENTION: Updated version, on some older models it may be necessary to modify the connection fittings, the pipes and the sheet metal near the support
